Molding Machine
The DKM standard Molding Machine is defined as the universal plastic processing industry. It adopts international famous brand high quality parts, have good stability, long life time, high performance, and can produce most of plastic products.
Machine Dimension
A
a
B
b
C
c
D
d
e
f
g
DKM50
3100
255
2500
120~320
1150
3
1600
100
SR10
135
20
DKM88
3600
295
2950
150~370
1100
3
1800
125
SR10
175
30
DKM118
4200
330
3170
150~380
1200
3
1800
125
Sr10
196
30
DKM138
4600
343
3520
150~430
1200
3
1850
125
Sr10
200
30
DKM188
5000
420
3850
180~500
1250
3
2000
125
Sr10
234
30
DKM218
5500
470
4450
200~530
1350
3
2100
160
SR10
240
30
DKM268
5800
545
4650
230~570
1450
3
2200
160
SR10
292
30
DKM330
7000
630
5730
270~670
1700
3
2300
160
SR15
400
30
DKM380
7200
670
5940
250~720
1800
4
2500
160
Sr15
430
50
DKM500
8100
740
6830
350~850
2000
4
2800
200
SR15
455
50
DKM650
9900
900
9157
400~900
2500
4
3800
200
SR15
550
50
DKM780
11000
980
9737
400~1000
2600
6
3800
250
SR20
675
50
DKM1080
12000
1200
10555
500~1200
2800
6
4000
250
SR20
750
50
DKM1250
13700
1300
11670
550~1300
3100
6
4100
250
SR20
1000
50
DKM1600
15000
1520
12589
700~1500
3500
8
4200
315
SR20
1120
50
The listed plastic injection molding machine's parameters is for reference only; DAKUMAR reserves the right to modify the information, without notice.
